Suitable for : Cutting iron, stainless, steel, aluminum, copper and various metals
- FEATURES
- Smooth & fast cut
- Stainless cut
- More efficient & durable
◆ Double Reinforcement
| For General Steel & Stainless Steel / INOX | ||||||||||
|---|---|---|---|---|---|---|---|---|---|---|
  |
CODE | SIZE | SPEC | MAX OPERATING SPEED | Inner Q'TY (pcs) | Outer Q'TY (pcs) | Surface | - | ||
| mm | inch | m/s | rpm (min-1) | |||||||
| Type-41 | UC-100-1.6A46S | 100x1.6x16 | 4"x1/16"x5/8" | A46S | 80 | 15,300 | 50 | 400 | - | ◆ |
| UC-100-2A30T | 100x2x16 | 4"x1/8"x5/8" | A30T | 25 | 200 | - | ||||
| UC-100-3A30T | 100x3x16 | 4"x3/32"x5/8" | A30T | 25 | 200 | |||||
| UC-180-3A30T | 180x3x22.23 | 7"x1/8"x7/8" | A30T | 80 | 8,500 | 25 | 100 | |||
Type-41 |
UC-305-3A30P | 305x3x25.4 | 12"x1/8"x1" | A30P | 80 | 5,100 | - | 50 | Smooth | |
| UC-355-3A30P | 355x3x25.4 | 14"x1/8"x1" | A30P | 80 | 4,400 | 50 | ||||
| UC-405-3A30P | 405x3x25.4 | 16"x1/8"x1" | A30P | 80 | 3,800 | 50 | ||||
| UC-355-2.8A36R | 355x2.8x25.4 | 14"x7/64"x1" | A36R | 80 | 4,400 | 50 | Rough |
|||
| UC-405-3A36R | 405x3x25.4 | 16"x1/8"x1" | A36R | 80 | 3,800 | 50 | ||||
Suitable for : Cut stainless, iron, steel, aluminum, copper and pipes, sheet etc. of metals
- FEATURES
- Cut more precisely and quickly
- Gold : Optimal performance, super sharp and durable
- Gray : Economical, sharp and durable
Gold
Gray
Gray
◆ Double Reinforcement
| For General Steel & Stainless Steel / INOX | |||||||||
|---|---|---|---|---|---|---|---|---|---|
|
CODE | SIZE | SPEC | MAX OPERATING SPEED | Inner Q'TY (pcs) | Outer Q'TY (pcs) | - | ||
| mm | inch | m/s | rpm (min-1) | ||||||
| Type-41 | UC-100-1A60T | 100x1.0x16 | 4"x3/64"x5/8" | A60T | 80 | 15,300 | 50 | 400 | ◆ |
UC-100-1A60U |
105x1.0x16 | 4"x3/64"x5/8" | A60U | 80 | 14,450 | 25 | 200 | ◆ |
|
| PICTOGRAM INFORMATION | |||||||
|---|---|---|---|---|---|---|---|
|
Do not use if damaged | |
Wear ear protection |  |
Only to be used with a back-up pad |  |
Sanding |
|
Do not use for face grinding | |
Wear eye protection |  |
Grinding | |
Metal steel |
 |
Do not use with hand-held grinding machine | |
Wear a mask | |
Cutting | |
Stainless steel / INOX |
|
Refer to instruction manual | |
Wear protective gloves |  |
Polishing |  |
Masonry |
SAFETY FIRST
Always use properly guarded tools, follow maximum operating speed recommendation and wear proper face and body protection.
